DARTS/Astro Query System - SQL Search -

All the tables available for SQL Search and information on each table are listed in the Available Data page. Please see the User Guide for the usage of "SQL Search".

Call example

【Basic Syntax】

 SELECT {*|column, column, column,..}
 FROM table name
 [ WHERE conditions ]
 [ ORDER BY column, column,... ]
 [ LIMIT {ALL|number} ] [ OFFSET number ]
 ;

---------------------------------------------------------

This is an example query to obtain the first 10 rows of
akari_fis_bsc_1 using radial search.

The akari_fis_bsc_1 is an catalogue, and each data has
the coorinate position of the object. So, search the objects
contained in the circle area you specify there.

Columns to display -> all
  Table name -> akari_fis_bsc_1
  Search condition -> radial search,
   center position is (266.0, -28,0) and radius is 10 arcmin
  Displayed results -> from 1st to 10th

---------------------------------------------------------
Point:
  You can use functions of PgSphere(https://pgsphere.github.io/)
  on this system.

Data types:
    Point   ... spoint(coordinate, coordinate)
    Path    ... spath(spoint(), spoint(), ...)
    Circle  ... scircle(spoint(), radius)
    Polygon ... spoly(spoint(), spoint(), ...)

Operators:
    a @ b = '1' ... a contained by b
    a !@ b = '1' ... a is not contained by b
    a && b = '1' ... overlaped each other
    a !&& b = '1' ... do not overlaped each other

Ths function radians needs a parameter in degree.
  Operator '/' means division.
  Note: integer division truncates the result.
   10.0 / 60.0 = 0.16666...
   10 / 60 = 0

---------------------------------------------------------

This is an example query to obtain the first 10 rows of
ginga_observation_log using radial search.

The ginga_observation_log has pointing observations and
scan observation. Each data has the coorinate of the
observation start point and the end point, and the
average point. So, search the pointing position contained
in the circle area you specified, or the scan-path crossed
over the area.

Columns to display -> all
  Table name -> ginga_observation_log
  Search condition -> radial search,
  center position is M31(10.7, 41.2) and radius is 1 degree
  Displayed results -> from 1st to 10th

---------------------------------------------------------
Point:
  You can use functions of PgSphere(https://pgsphere.github.io/)
  on this system.

Data types:
    Point   ... spoint(coordinate, coordinate)
    Path    ... spath(spoint(), spoint(), ...)
    Circle  ... scircle(spoint(), radius)
    Polygon ... spoly(spoint(), spoint(), ...)

Operators:
    a @ b  ... a contained by b
    a !@ b ... a is not contained by b
    a && b ... overlaped each other
    a !&& b ... do not overlaped each other

---------------------------------------------------------

This is an example query to obtain the data near the
galactic center of suzaku_xis_observation_log using radial search.

The SUZAKU XIS has rectanglar field of view with 18 arcmin
x 18 arcmin. Each data of suzaku_xis_observation_log has
the coorinate of each corner position about field of view.
So, search the rectanglar area overlapd the circle area
you specified.

Columns to display -> all
  Table name -> suzaku_xis_observation_log
  Search condition -> radial search,
    center position is (0.0, 0.0) with Galactic coordinates
    and radius is 1 arcmin
  Displayed results -> from 1st to 200th

---------------------------------------------------------
Point:

1. Use the column of Galactic coordinates.

2. You can use functions of PgSphere(https://pgsphere.github.io/)
   on this system.

Data types:
    Point   ... spoint(coordinate, coordinate)
    Path    ... spath(spoint(), spoint(), ...)
    Circle  ... scircle(spoint(), radius)
    Polygon ... spoly(spoint(), spoint(), ...)

Operators:
    a @ b  ... a contained by b
    a !@ b ... a is not contained by b
    a && b ... overlaped each other
    a !&& b ... do not overlaped each other

---------------------------------------------------------

This is an example query to obtain the data nearthe
galactic center of suzaku_xis_observation_log using radial search.

The SUZAKU XIS has rectanglar field of view with 18 arcmin
x 18 arcmin. Each data of suzaku_xis_observation_log has the
coorinate of each corner position about field of view.
So, search the rectanglar area overlapd the rectanglar area
you specified.

Columns to display -> object_name, center_galactic_lon,
   center_galactic_lat, data_access_url
  Table name -> suzaku_xis_observation_log
  Search condition -> rectanglar search,
    0.1(deg) <= Galactic Latitude <= .0.1(deg)
    and 0.1(deg) <= Galactic Latitude <= 0.1(deg)
  Displayed results -> from 1st to 100th

---------------------------------------------------------
Point:
  You can use functions of PgSphere(https://pgsphere.github.io/)
  on this system.

Data types:
    Point   ... spoint(coordinate, coordinate)
    Path    ... spath(spoint(), spoint(), ...)
    Circle  ... scircle(spoint(), radius)
    Polygon ... spoly(spoint(), spoint(), ...)

Operators:
    a @ b  ... a contained by b
    a !@ b ... a is not contained by b
    a && b ... overlaped each other
    a !&& b ... do not overlaped each other

---------------------------------------------------------

This is an example query to obtain the first 10 rows of
akari_fis_bsc_1 using radial search.

The akari_fis_bsc_1 is an catalogue, and each data has
the coorinate position of the object. So, search the objects
contained in the circle area you specify there.

Columns to display -> all
  Table name -> akari_fis_bsc_1
  Search condition -> radial search,
   center position is (266.0, -28,0) and radius is 10 arcmin
  Displayed results -> from 1st to 10th

---------------------------------------------------------
Point:
  You can use functions of PgSphere(https://pgsphere.github.io/)
  on this system.

Data types:
    Point   ... spoint(coordinate, coordinate)
    Path    ... spath(spoint(), spoint(), ...)
    Circle  ... scircle(spoint(), radius)
    Polygon ... spoly(spoint(), spoint(), ...)

Operators:
    a @ b = '1' ... a contained by b
    a !@ b = '1' ... a is not contained by b
    a && b = '1' ... overlaped each other
    a !&& b = '1' ... do not overlaped each other

Ths function radians needs a parameter in degree.
  Operator '/' means division.
  Note: integer division truncates the result.
   10.0 / 60.0 = 0.16666...
   10 / 60 = 0

---------------------------------------------------------

This is an example query to obtain the first 10 rows of
ginga_observation_log using radial search.

---------------------------------------------------------
Point:
  You can use functions of PgSphere(https://pgsphere.github.io/)
  on this system.

Data types:
    Point   ... spoint(coordinate, coordinate)
    Path    ... spath(spoint(), spoint(), ...)
    Circle  ... scircle(spoint(), radius)
    Polygon ... spoly(spoint(), spoint(), ...)

Operators:
    a @ b  ... a contained by b
    a !@ b ... a is not contained by b
    a && b ... overlaped each other
    a !&& b ... do not overlaped each other

---------------------------------------------------------

This is an example query to obtain the data near the
galactic center of suzaku_xis_observation_log using radial search.

---------------------------------------------------------
Point:

1. Use the column of Galactic coordinates.

2. You can use functions of PgSphere(https://pgsphere.github.io/)
   on this system.

Data types:
    Point   ... spoint(coordinate, coordinate)
    Path    ... spath(spoint(), spoint(), ...)
    Circle  ... scircle(spoint(), radius)
    Polygon ... spoly(spoint(), spoint(), ...)

Operators:
    a @ b  ... a contained by b
    a !@ b ... a is not contained by b
    a && b ... overlaped each other
    a !&& b ... do not overlaped each other

---------------------------------------------------------

This is an example query to obtain the data nearthe
galactic center of suzaku_xis_observation_log using radial search.

The SUZAKU XIS has rectanglar field of view with 18 arcmin
x 18 arcmin. Each data of suzaku_xis_observation_log has the
coorinate of each corner position about field of view.
So, search the rectanglar area overlapd the rectanglar area
you specified.

---------------------------------------------------------
Point:
  You can use functions of PgSphere(https://pgsphere.github.io/)
  on this system.

Data types:
    Point   ... spoint(coordinate, coordinate)
    Path    ... spath(spoint(), spoint(), ...)
    Circle  ... scircle(spoint(), radius)
    Polygon ... spoly(spoint(), spoint(), ...)

Operators:
    a @ b  ... a contained by b
    a !@ b ... a is not contained by b
    a && b ... overlaped each other
    a !&& b ... do not overlaped each other

---------------------------------------------------------

SQL query

Format

total 1

Download WgetScript

No.	observation_id	ql_image_url	ql_access_url	object_name	object_type	center_ra	center_dec	center_ra_b1950	center_dec_b1950	center_ecliptic_lon	center_ecliptic_lat	center_galactic_lon	center_galactic_lat	euler_angle_1	euler_angle_2	euler_angle_3	offset_x	offset_y	observation_status	expect_observation_date	observation_start_time	observation_start_time_mjd	observation_end_time	observation_end_time_mjd	awarded_exposure	gis_exposure	sis_exposure	total_elapsed_time	proposal_id	pi_name	proposal_category	proposal_priority	processing_date	processing_count	processing_version	distribution_date	expect_public_date	public_date	product_revision	db_create_date	data_access_url
1	73012010		Quick Look	3C279	AGN UNCLASSIFIED	194.124985	-5.751353	193.477781	-5.480984	195.222284	0.266349	305.250314	57.097607	193.840393	95.776398	337.272614	-4	3.5	archived	1995-01-08 11:15:55	1995-01-08 00:00:00	49725	1995-01-08 00:00:00	49725	10	10.6	10.2	22480	0	KII	AGN	2	1998-04-19 00:00:00	4	7.2.3	1995-02-09 00:00:00	1996-08-28 00:00:00	2000-02-04 00:00:00	2	2000-02-04 00:00:00	https://data.darts.isas.jaxa.jp/pub/asca/data/73012010/

Used SQL

SELECT * FROM asca_master_data WHERE observation_id = '73012010'

Your request has been accepted.
The download will start soon automatically.
