DARTS/Astro Query System - SQL Search -

All the tables available for SQL Search and information on each table are listed in the Available Data page. Please see the User Guide for the usage of "SQL Search".

Call example

【Basic Syntax】

 SELECT {*|column, column, column,..}
 FROM table name
 [ WHERE conditions ]
 [ ORDER BY column, column,... ]
 [ LIMIT {ALL|number} ] [ OFFSET number ]
 ;

---------------------------------------------------------

This is an example query to obtain the first 10 rows of
akari_fis_bsc_1 using radial search.

The akari_fis_bsc_1 is an catalogue, and each data has
the coorinate position of the object. So, search the objects
contained in the circle area you specify there.

Columns to display -> all
  Table name -> akari_fis_bsc_1
  Search condition -> radial search,
   center position is (266.0, -28,0) and radius is 10 arcmin
  Displayed results -> from 1st to 10th

---------------------------------------------------------
Point:
  You can use functions of PgSphere(https://pgsphere.github.io/)
  on this system.

Data types:
    Point   ... spoint(coordinate, coordinate)
    Path    ... spath(spoint(), spoint(), ...)
    Circle  ... scircle(spoint(), radius)
    Polygon ... spoly(spoint(), spoint(), ...)

Operators:
    a @ b = '1' ... a contained by b
    a !@ b = '1' ... a is not contained by b
    a && b = '1' ... overlaped each other
    a !&& b = '1' ... do not overlaped each other

Ths function radians needs a parameter in degree.
  Operator '/' means division.
  Note: integer division truncates the result.
   10.0 / 60.0 = 0.16666...
   10 / 60 = 0

---------------------------------------------------------

This is an example query to obtain the first 10 rows of
ginga_observation_log using radial search.

The ginga_observation_log has pointing observations and
scan observation. Each data has the coorinate of the
observation start point and the end point, and the
average point. So, search the pointing position contained
in the circle area you specified, or the scan-path crossed
over the area.

Columns to display -> all
  Table name -> ginga_observation_log
  Search condition -> radial search,
  center position is M31(10.7, 41.2) and radius is 1 degree
  Displayed results -> from 1st to 10th

---------------------------------------------------------
Point:
  You can use functions of PgSphere(https://pgsphere.github.io/)
  on this system.

Data types:
    Point   ... spoint(coordinate, coordinate)
    Path    ... spath(spoint(), spoint(), ...)
    Circle  ... scircle(spoint(), radius)
    Polygon ... spoly(spoint(), spoint(), ...)

Operators:
    a @ b  ... a contained by b
    a !@ b ... a is not contained by b
    a && b ... overlaped each other
    a !&& b ... do not overlaped each other

---------------------------------------------------------

This is an example query to obtain the data near the
galactic center of suzaku_xis_observation_log using radial search.

The SUZAKU XIS has rectanglar field of view with 18 arcmin
x 18 arcmin. Each data of suzaku_xis_observation_log has
the coorinate of each corner position about field of view.
So, search the rectanglar area overlapd the circle area
you specified.

Columns to display -> all
  Table name -> suzaku_xis_observation_log
  Search condition -> radial search,
    center position is (0.0, 0.0) with Galactic coordinates
    and radius is 1 arcmin
  Displayed results -> from 1st to 200th

---------------------------------------------------------
Point:

1. Use the column of Galactic coordinates.

2. You can use functions of PgSphere(https://pgsphere.github.io/)
   on this system.

Data types:
    Point   ... spoint(coordinate, coordinate)
    Path    ... spath(spoint(), spoint(), ...)
    Circle  ... scircle(spoint(), radius)
    Polygon ... spoly(spoint(), spoint(), ...)

Operators:
    a @ b  ... a contained by b
    a !@ b ... a is not contained by b
    a && b ... overlaped each other
    a !&& b ... do not overlaped each other

---------------------------------------------------------

This is an example query to obtain the data nearthe
galactic center of suzaku_xis_observation_log using radial search.

The SUZAKU XIS has rectanglar field of view with 18 arcmin
x 18 arcmin. Each data of suzaku_xis_observation_log has the
coorinate of each corner position about field of view.
So, search the rectanglar area overlapd the rectanglar area
you specified.

Columns to display -> object_name, center_galactic_lon,
   center_galactic_lat, data_access_url
  Table name -> suzaku_xis_observation_log
  Search condition -> rectanglar search,
    0.1(deg) <= Galactic Latitude <= .0.1(deg)
    and 0.1(deg) <= Galactic Latitude <= 0.1(deg)
  Displayed results -> from 1st to 100th

---------------------------------------------------------
Point:
  You can use functions of PgSphere(https://pgsphere.github.io/)
  on this system.

Data types:
    Point   ... spoint(coordinate, coordinate)
    Path    ... spath(spoint(), spoint(), ...)
    Circle  ... scircle(spoint(), radius)
    Polygon ... spoly(spoint(), spoint(), ...)

Operators:
    a @ b  ... a contained by b
    a !@ b ... a is not contained by b
    a && b ... overlaped each other
    a !&& b ... do not overlaped each other

---------------------------------------------------------

This is an example query to obtain the first 10 rows of
akari_fis_bsc_1 using radial search.

The akari_fis_bsc_1 is an catalogue, and each data has
the coorinate position of the object. So, search the objects
contained in the circle area you specify there.

Columns to display -> all
  Table name -> akari_fis_bsc_1
  Search condition -> radial search,
   center position is (266.0, -28,0) and radius is 10 arcmin
  Displayed results -> from 1st to 10th

---------------------------------------------------------
Point:
  You can use functions of PgSphere(https://pgsphere.github.io/)
  on this system.

Data types:
    Point   ... spoint(coordinate, coordinate)
    Path    ... spath(spoint(), spoint(), ...)
    Circle  ... scircle(spoint(), radius)
    Polygon ... spoly(spoint(), spoint(), ...)

Operators:
    a @ b = '1' ... a contained by b
    a !@ b = '1' ... a is not contained by b
    a && b = '1' ... overlaped each other
    a !&& b = '1' ... do not overlaped each other

Ths function radians needs a parameter in degree.
  Operator '/' means division.
  Note: integer division truncates the result.
   10.0 / 60.0 = 0.16666...
   10 / 60 = 0

---------------------------------------------------------

This is an example query to obtain the first 10 rows of
ginga_observation_log using radial search.

---------------------------------------------------------
Point:
  You can use functions of PgSphere(https://pgsphere.github.io/)
  on this system.

Data types:
    Point   ... spoint(coordinate, coordinate)
    Path    ... spath(spoint(), spoint(), ...)
    Circle  ... scircle(spoint(), radius)
    Polygon ... spoly(spoint(), spoint(), ...)

Operators:
    a @ b  ... a contained by b
    a !@ b ... a is not contained by b
    a && b ... overlaped each other
    a !&& b ... do not overlaped each other

---------------------------------------------------------

This is an example query to obtain the data near the
galactic center of suzaku_xis_observation_log using radial search.

---------------------------------------------------------
Point:

1. Use the column of Galactic coordinates.

2. You can use functions of PgSphere(https://pgsphere.github.io/)
   on this system.

Data types:
    Point   ... spoint(coordinate, coordinate)
    Path    ... spath(spoint(), spoint(), ...)
    Circle  ... scircle(spoint(), radius)
    Polygon ... spoly(spoint(), spoint(), ...)

Operators:
    a @ b  ... a contained by b
    a !@ b ... a is not contained by b
    a && b ... overlaped each other
    a !&& b ... do not overlaped each other

---------------------------------------------------------

This is an example query to obtain the data nearthe
galactic center of suzaku_xis_observation_log using radial search.

The SUZAKU XIS has rectanglar field of view with 18 arcmin
x 18 arcmin. Each data of suzaku_xis_observation_log has the
coorinate of each corner position about field of view.
So, search the rectanglar area overlapd the rectanglar area
you specified.

---------------------------------------------------------
Point:
  You can use functions of PgSphere(https://pgsphere.github.io/)
  on this system.

Data types:
    Point   ... spoint(coordinate, coordinate)
    Path    ... spath(spoint(), spoint(), ...)
    Circle  ... scircle(spoint(), radius)
    Polygon ... spoly(spoint(), spoint(), ...)

Operators:
    a @ b  ... a contained by b
    a !@ b ... a is not contained by b
    a && b ... overlaped each other
    a !&& b ... do not overlaped each other

---------------------------------------------------------

SQL query

Format

total 10

Download WgetScript

No.	observation_code	observation_id	observation_status	analyst	analysis_status	ql_image_url	ql_access_url	remarks	related_observation_code	object_name	object_name_alternative	object_ra	object_dec	object_ra_b1950	object_dec_b1950	object_ecliptic_lon	object_ecliptic_lat	object_galactic_lon	object_galactic_lat	coordinate_system	position_reference	frequency	integration_time	quantity_of_if_channel	quantity_of_spectral_channel	observation_start_year	observation_start_day_of_year	observation_start_date	observation_start_time	observation_start_time_mjd	observation_end_time	observation_end_time_mjd	exposure	exposure_hour	flux_density	quantity_of_ground_radio_telescope	ground_radio_telescope	tracking_station	correlator	data_access_url	is_tape_at_isas
1	vs03l	vs03l_19980222		Dodson	Complete		Quick Look	No Kashima or Usuda or Ceduna . Paper III		J1626-2951	QSO B1622-297,PKS 1622-297,B1622-2944	246.5251	-29.8575	245.73853	-29.74483	249.57835	-8.06735	348.81717	13.31553	J2000	USNO - Ref Frame 1995-1, Eubanks Mar 1995	5	1	2	256	1998	53	1998-02-22	1998-02-22 22:00:00	50866.91667	1998-02-23 03:00:00	50867.125	18	5	3	4	MP HO SH HH	TZ	Penticton	https://data.darts.isas.jaxa.jp/pub/halca/VSOP_5GHz_AGN_SurveyProgram/analysis_results/vs03l_1998_53_dodson/	Y
2	vs03l	vs03l_19980222		Lovell	Complete		Quick Look	No Kashima or Usuda or Ceduna . Paper III		J1626-2951	QSO B1622-297,PKS 1622-297,B1622-2944	246.5251	-29.8575	245.73853	-29.74483	249.57835	-8.06735	348.81717	13.31553	J2000	USNO - Ref Frame 1995-1, Eubanks Mar 1995	5	1	2	256	1998	53	1998-02-22	1998-02-22 22:00:00	50866.91667	1998-02-23 03:00:00	50867.125	18	5	3	4	MP HO SH HH	TZ	Penticton	https://data.darts.isas.jaxa.jp/pub/halca/VSOP_5GHz_AGN_SurveyProgram/analysis_results/vs03l_1998_53_lovell/	Y
3	vs03l	vs03l_19980222		Paragi	Complete		Quick Look	No Kashima or Usuda or Ceduna . Paper III		J1626-2951	QSO B1622-297,PKS 1622-297,B1622-2944	246.5251	-29.8575	245.73853	-29.74483	249.57835	-8.06735	348.81717	13.31553	J2000	USNO - Ref Frame 1995-1, Eubanks Mar 1995	5	1	2	256	1998	53	1998-02-22	1998-02-22 22:00:00	50866.91667	1998-02-23 03:00:00	50867.125	18	5	3	4	MP HO SH HH	TZ	Penticton	https://data.darts.isas.jaxa.jp/pub/halca/VSOP_5GHz_AGN_SurveyProgram/analysis_results/vs03l_1998_53_paragi/	Y
4	vs03l	vs03l_19980222		Shen	Complete		Quick Look	No Kashima or Usuda or Ceduna . Paper III		J1626-2951	QSO B1622-297,PKS 1622-297,B1622-2944	246.5251	-29.8575	245.73853	-29.74483	249.57835	-8.06735	348.81717	13.31553	J2000	USNO - Ref Frame 1995-1, Eubanks Mar 1995	5	1	2	256	1998	53	1998-02-22	1998-02-22 22:00:00	50866.91667	1998-02-23 03:00:00	50867.125	18	5	3	4	MP HO SH HH	TZ	Penticton	https://data.darts.isas.jaxa.jp/pub/halca/VSOP_5GHz_AGN_SurveyProgram/analysis_results/vs03l_1998_53_shen/	Y
5	vs03l	vs03l_19980222		Tingay	Complete		Quick Look	No Kashima or Usuda or Ceduna . Paper III		J1626-2951	QSO B1622-297,PKS 1622-297,B1622-2944	246.5251	-29.8575	245.73853	-29.74483	249.57835	-8.06735	348.81717	13.31553	J2000	USNO - Ref Frame 1995-1, Eubanks Mar 1995	5	1	2	256	1998	53	1998-02-22	1998-02-22 22:00:00	50866.91667	1998-02-23 03:00:00	50867.125	18	5	3	4	MP HO SH HH	TZ	Penticton	https://data.darts.isas.jaxa.jp/pub/halca/VSOP_5GHz_AGN_SurveyProgram/analysis_results/vs03l_1998_53_tingay/	Y
6	vs03l	vs03l_19980222		Lister	Complete		Quick Look	No Kashima or Usuda or Ceduna . Paper III		J1626-2951	QSO B1622-297,PKS 1622-297,B1622-2944	246.5251	-29.8575	245.73853	-29.74483	249.57835	-8.06735	348.81717	13.31553	J2000	USNO - Ref Frame 1995-1, Eubanks Mar 1995	5	1	2	256	1998	53	1998-02-22	1998-02-22 22:00:00	50866.91667	1998-02-23 03:00:00	50867.125	18	5	3	4	MP HO SH HH	TZ	Penticton	https://data.darts.isas.jaxa.jp/pub/halca/VSOP_5GHz_AGN_SurveyProgram/analysis_results/vs03l_1998_53_lister/	Y
7	vs03l	vs03l_19980222		Scott	Complete		Quick Look	No Kashima or Usuda or Ceduna . Paper III		J1626-2951	QSO B1622-297,PKS 1622-297,B1622-2944	246.5251	-29.8575	245.73853	-29.74483	249.57835	-8.06735	348.81717	13.31553	J2000	USNO - Ref Frame 1995-1, Eubanks Mar 1995	5	1	2	256	1998	53	1998-02-22	1998-02-22 22:00:00	50866.91667	1998-02-23 03:00:00	50867.125	18	5	3	4	MP HO SH HH	TZ	Penticton	https://data.darts.isas.jaxa.jp/pub/halca/VSOP_5GHz_AGN_SurveyProgram/analysis_results/vs03l_1998_53_scott/	Y
8	vs03l	vs03l_19980222		Piner	Complete		Quick Look	No Kashima or Usuda or Ceduna . Paper III		J1626-2951	QSO B1622-297,PKS 1622-297,B1622-2944	246.5251	-29.8575	245.73853	-29.74483	249.57835	-8.06735	348.81717	13.31553	J2000	USNO - Ref Frame 1995-1, Eubanks Mar 1995	5	1	2	256	1998	53	1998-02-22	1998-02-22 22:00:00	50866.91667	1998-02-23 03:00:00	50867.125	18	5	3	4	MP HO SH HH	TZ	Penticton	https://data.darts.isas.jaxa.jp/pub/halca/VSOP_5GHz_AGN_SurveyProgram/analysis_results/vs03l_1998_53_piner/	Y
9	vs03l	vs03l_19980222		Horiuchi	Complete		Quick Look	No Kashima or Usuda or Ceduna . Paper III		J1626-2951	QSO B1622-297,PKS 1622-297,B1622-2944	246.5251	-29.8575	245.73853	-29.74483	249.57835	-8.06735	348.81717	13.31553	J2000	USNO - Ref Frame 1995-1, Eubanks Mar 1995	5	1	2	256	1998	53	1998-02-22	1998-02-22 22:00:00	50866.91667	1998-02-23 03:00:00	50867.125	18	5	3	4	MP HO SH HH	TZ	Penticton	https://data.darts.isas.jaxa.jp/pub/halca/VSOP_5GHz_AGN_SurveyProgram/analysis_results/vs03l_1998_53_horiuchi/	Y
10	vs03l	vs03l_19980222		Wajima	Underway			No Kashima or Usuda or Ceduna . Paper III		J1626-2951	QSO B1622-297,PKS 1622-297,B1622-2944	246.5251	-29.8575	245.73853	-29.74483	249.57835	-8.06735	348.81717	13.31553	J2000	USNO - Ref Frame 1995-1, Eubanks Mar 1995	5	1	2	256	1998	53	1998-02-22	1998-02-22 22:00:00	50866.91667	1998-02-23 03:00:00	50867.125	18	5	3	4	MP HO SH HH	TZ	Penticton		Y

Used SQL

SELECT * FROM halca_survey_analysis WHERE observation_id= 'vs03l_19980222'
